Features:
- Slim, narrow design for optimum handling
- The powerful and handy tool for cutouts of all kinds
- Working to scribe mark and template easily possible
Technical Data
- Cutting capacity in steel (400 N/mm²), max.:1.6 mm
- No-load stroke rate:2,600 spm
- Material that can be processed
- Steel up to 400 N/mm² at 1.6 mm
- Cutting track width:5 mm
- Pre-drilling for interior cut-outs:21 mm
- Smallest radius:40 mm
- Stroke rate under load:2,100 spm
- Weight:1.8 kg
- Tool dimensions (length):290 mm
- Tool dimensions (height):142 mm
- Cutting capacity in steel (600 N/mm²), max.:1 mm
- Cutting capacity in steel (800 N/mm²), max.:0.7 mm
- Cutting capacity in aluminium (200 N/mm²), max.:2 mm
Electric specifications
- Rated input power:750 W
- Power output:400 W
Total vibration values (Cutting sheet metal)
- Vibration emission value ah:6 m/s²
- Uncertainty K:1.5 m/s²
Noise/vibration information
- Sound pressure level:90 dB(A)
- Sound power level:101 dB(A)
- Uncertainty K:3 dB
Cutting sheet metal
- Vibration emission value ah:6 m/s²
- Uncertainty K:1.5 m/s²
