Samsung 18000 BTU Inverter Split Air Conditioner, Wall-mount AC with Energy Saving (AR18BVHGAWK/AF R410A)

1. Good Sleep
2. HD Filter
3. Dehumidification

Specifications

Capacity

1. Cooling (Btu/hr): 17,000 Btu/hr
2. Cooling (kW): 4.98 kW
3. Cooling (Min - Max, Btu/hr): 2,559 - 18,084 Btu/hr
4. Cooling (Min - Max, kW): 0.75 - 5.30 kW

Energy Efficiency

1. EER (Cooling, W/W): 3.00 W/W
2. EER (Cooling, Btu/hW): 10.24 Btu/hW

Noise Level

1. Indoor (High/Low, dBA): 44/36 dBA
2. Outdoor (High/Low, dBA): 53.5 dBA

Electrical Data

1. Power Source (Φ/V/Hz): 1 / 220-240 / 50
2. Power Consumption (Cooling, W): 1660 W
3. Operating Current (Cooling, A): 7.2 A

Physical Specifications

1. Gross Dimension (Indoor, WxHxD, mm): 1041 × 320 × 383 mm
2. Gross Dimension (Outdoor, WxHxD, mm): 872 × 620 × 398 mm
3. Net Dimension (Indoor, WxHxD, mm): 970 × 300 × 224 mm
4. Net Dimension (Outdoor, WxHxD, mm): 802 × 555 × 350 mm
5. Gross Weight (Indoor, kg): 17.5 kg
6. Gross Weight (Outdoor, kg): 33.0 kg
7. Net Weight (Indoor, kg): 13.5 kg
8. Net Weight (Outdoor, kg): 27.5 kg
9. Loading Quantity (20/40/40Hft with Pipe): 79/163/196

Technical Information

1. Piping Length (Max, m): 25 m
2. Piping Height (Max, m): 10 m
3. SVC Valve (Liquid (ODxL)): φ6
4. SVC Valve (Gas (ODxL)): φ12
5. Moisture Removal (l/hr): 1.80 l/hr
6. Air Circulation (Cooling, ㎥/min): 850 ㎥/min
7. Refrigerant (Type): R410A
8. Refrigerant (Charging, kg): 0.95 kg
9. Low Ambient (Cooling, ℃): 18~48 ℃

Air Flow

1. Air Direction Control (Up/Down): Auto
2. Air Direction Control (Left/Right): Manual
3. Air Flow Control Step (Cool/Fan): 3 Step

Air Purification

1. Auto Clean (Self Cleaning): No

Convenience

1. Filter Cleaning Indicator: No
2. Indoor Temperature Display: Yes
3. Display On/Off: Yes
4. Beep On/Off: No
5. 24-Hour Timer: Yes
6. Auto Changeover: No
7. Auto Restart: Yes

Operating Mode

1. Fast Cool: Yes
2. Good Sleep: Yes
3. Dehumidification: Yes
4. Fan Mode: Yes
5. Quiet: No
