Features:
- For heavy screw joints on trucks, construction machinery, in commercial vehicle construction, in the petrochemical and other heavy industries
- Auxiliary handle with backing pad that can be fitted in two positions for better handling
- Hanging hook for attaching to a balancer
- For heavy screw joints on trucks, construction machinery, in commercial vehicle construction, in the petrochemical and other heavy industries
- Hanging hook for attaching to a balancer High impact performance with low weight Torsion bars (special accessory) guarantee adherence to desired torque Auxiliary handle with backing pad that can be fitted in two positions for better handling V-groove
- impact mechanism with low recoil torque and long lifetime Forward/reverse rotation for tightening and loosening Easy-to-change tools
Specifications:
- Rated power input :920 W
- Torque, max. (hard screw driving applications): 1,000 Nm
- Torque, max. (soft screw driving applications): 500 Nm
- Bit holder :3/4'' Square
- Rated speed :860 rpm
- No-load speed :800 – 1900 rpm
- Weight :7.3 kg
- Length: 431 mm
- Height: 436 mm
Screw driving
- Screw diameter: max. M 30
Tightening screws and nuts of maximum permitted size
- Vibration emission value ah :4 m/s²
- Uncertainty K :0.5 m/s²
Total vibration values (Tightening screws and nuts of maximum permitted size)
- Vibration emission value ah:4 m/s²
- Uncertainty K:0.5 m/s²
Noise/vibration information
- Sound pressure level:100 dB(A)
- Sound power level:113 dB(A)
- Uncertainty K:3 dB
