Hisense 18,000 BTU Slim Ducted Air Conditioner | Inverter | 3.5 EER | R32 | Low-Profile Indoor Unit | Wired Controller

The Hisense ADT-18UX4RCL8 is a slim ducted inverter air conditioner designed for spaces that require discreet climate control without compromising performance. With a cooling capacity of 18,000 BTU (5.0 kW) and a heating capacity of 5.5 kW, it ensures year-round comfort, energy efficiency, and quiet operation.

Technical Specifications

Power Supply

1. Rated Voltage: 220V / 3 Phase / 50Hz

Warranty

1. 1 Year on Parts and Compressor

Electrical Input

1. Indoor Unit: 220–240V / 1Ph / 50 & 60Hz
2. Outdoor Unit: 220–240V / 1Ph / 50 & 60Hz
3. Max Power Input: 2,200 W
4. Max Current: 13.5 A

Cooling Performance

1. Rated Cooling Capacity: 17,060 BTU/h (5,000 W)
2. Capacity Range: 5,118 ~ 20,472 BTU/h (1,500 ~ 6,000 W)
3. Rated Power Consumption: 1,429 W
4. Rated Current: 6.2 A
5. EER: 3.50 W/W

Heating Performance

1. Rated Heating Capacity: 18,766 BTU/h (5,500 W)
2. Capacity Range: 5,118 ~ 22,178 BTU/h (1,500 ~ 6,500 W)
3. Rated Power Consumption: 1,447 W
4. Rated Current: 6.3 A
5. COP: 3.80 W/W

Indoor Unit Specifications

1. Fan Motor: 1 Unit
2. Motor Power: 60 W
3. Dimensions (W×H×D): 1180 × 190 × 447 mm
4. Packaging Dimensions: 1350 × 285 × 565 mm
5. Net / Gross Weight: 24.5 / 29.5 kg
6. Airflow (High / Med / Low):
7. 900 / 840 / 780 m³/h
8. 529 / 494 / 459 CFM
9. Noise Level (SPL): 41 / 37 / 33 dB(A)
10. Sound Power Level (PWL): 57 dB(A)
11. Factory Static Pressure: 35 Pa
12. Adjustable Pressure Range: 0 ~ 50 Pa
13. Drain Pipe Diameter: OD Φ32 mm
14. Condensate Pump: Standard
15. Air Filter: Standard
16. Wired Controller Model: YXE-E01U(E)
17. Control Type: Wired
18. Design Pressure (H/L): 4.3 / 1.6 MPa
19. Temperature Range (Cooling/Heating): 16 ~ 30 ℃
