Features:
- Easy handling with horizontal and vertical self-levelling
- Easy to operate thanks to one button per function, and self-explanatory display
- Easy to set up in both the horizontal and vertical modes due to automatic self-levelling of 8% (± 5°)
- The shock warning function, which can be switched on and off, prevents levelling errors in the event of shocks and vibrations
Technical data
- Working range: 60 m
- Working range with receiver: 300 m (Diameter)
- Accuracy: ± 0.1 mm/m
- Laser diode: 635 nm, < 5>
- Operating temperature, from: -10 °C
- Operating temperature, up to: 50 °C
- Operating temperature: -10 – 50 °C
- Storage temperature, from: -20 °C
- Storage temperature, up to: 70 °C
- Storage temperature: -20 – 70 °C
- Laser class: 3R
- Working range with receiver, value: 300 m
- Working range with receiver, appendage: (Diameter)
- Working range without receiver, value: 60 m
- Working range without receiver, appendage: (Diameter)
- Working range without receiver: 60 m (Diameter)
- Self-levelling range: ± 5° (8%)
- Levelling time: 15 s
- Dust and splash protection: IP 54
- Rotation speed: 150, 300, 600 rpm
- Power supply: 2 x 1.2 V HR20 (D) (9 Ah), 2 x 1.5 V LR20 (D)
- Operating time (max.): Rechargeable batteries (NiMH) 30 h
- Tripod thread: 5/8"
- Weight, approx.: 1.8 kg
- Colour of laser line: Red
