Features :
- Improved performance for a fast drilling rate and high chiseling removal rate
- Reliable and robust with a long lifetime due to high-quality components
- Wide range of applications for drilling, hammer drilling and chiseling
Technical data
- Rated input power:830 W
- Impact energy (according to EPTA 05/2016):2.7 J
- Weight:2.9 kg
- Tool dimensions (width):83 mm
- Tool dimensions (length):407 mm
- Tool holder: SDS plus
- Tool dimensions (height):210 mm
Performance data
- Impact rate at rated speed:0 – 4,000 bpm
- Rated speed:0 – 900 rpm
Drilling range
- Drilling dia. concrete, hammer drill bits:4 – 26 mm
- Opt. appl. range concrete, hammer drill bits:8 – 16 mm
- Drilling diameter in concrete with core cutters:16 – 68 mm
- Max. drilling diameter masonry, core cutters:68 mm
- Max. drilling diameter in metal:13 mm
- Max. drilling diameter in wood:30 mm
