Key Features
- Maximum precision thanks to the Bosch Pendulum Precision System
- Projection of a vertical and a horizontal line
- Detachable, 360° rotating platform with bubble vial and fine adjustment
Technical Data
Additional Information
- Working Range: 15 m
- Working Range with Receiver: 15 m
- Accuracy: Horizontal Laser Line: ±0.2 mm/m; Vertical Laser Lines: ±0.3 mm/m
- Laser Line Color: Red
- Laser Diode: 630 – 650 nm, <1 mW
- Operating Temperature: -10 – 45 °C
- Storage Temperature: -20 – 70 °C
- Laser Class: 2
- Maximum Working Range of Laser Points: 5 m (bottom)
- Self-Levelling Range: ±3°
- Levelling Time: 4 s
- Power Supply: 4 x 1.5 V LR6 (AA)
- Maximum Operating Time: 24 h
- Approximate Weight: 0.72 kg
- Plumb Point Color: Red
- Projection: 3 Lines + 1 Plumb Point
- Plumb Point Accuracy: ±0.7 mm/m
