Features:
- Extreme cutting smoothness because of innovative and maintenance-free gliding system
- Integrated dual line laser supports accurate cuts
- High vertical and horizontal cutting capacity
Technical Data
- Saw blade diameter:305 mm
- Mitre setting:52 ° L / 60 ° R
- Bevel setting:47 ° L / 47 ° R
- Saw blade bore diameter:30 mm
- Rated input power:2,000 W
- Cutting capacity, 0°:104 x 341 mm
- Cutting capacity, 45° mitre
- 104 x 240 mm
- Cutting capacity, 45° bevel:51 x 341 mm
- Tool dimensions (width x length x height):1100 x670 x740 mm
- No-load speed:4,000 rpm
- Weight:32.1 kg
Total vibration values (Sawing wood)
- Vibration emission value ah:2.5 m/s²
- Uncertainty K:1.5 m/s²
Noise/vibration information
- Sound pressure level:93 dB(A)
- Sound power level:106 dB(A)
- Uncertainty K:3 dB
Sawing wood
- Vibration emission value ah:2.5 m/s²
- Uncertainty K:1.5 m/s²
