This is the most heavy-duty tool in Bosch’s SDS max corded rotary hammer range with Vibration Control. It features a high-end motor producing the ultimate performance in SDS max applications. The rotary hammer’s incredibly powerful motor enables the delivery of an impressive 19 J of impact energy, which is perfect for tough chiselling. It is also designed for high durability, featuring extremely robust metal components.
Equipment & Application
This tool is intended for drilling up to 52 mm in diameter and heavy chiselling work in concrete and stone. It is compatible with various dust attachments.
Additional Information
This rotary hammer features Constant Speed, Restart Protection, Rotation Control Clutch, Speed Selection, and Vibration Control for effortless and continuous work in time-intensive applications.
Key Features
- High-end motor for ultimate performance in SDS max tasks
- Highly durable due to extremely robust metal components
- Strong motor enables the delivery of an impressive 19 J of impact energy for heavy chiselling.
Technical Data
Performance Data
-
Impact Rate at Rated Speed: 1,025 – 2,100 bpm
-
Rated Speed: 105 – 215 rpm
Additional Data
-
Rated Input Power: 1,700 W
-
Impact Energy: 19 J
-
Tool Holder: SDS max
-
Voltage (Electrical): 230 V
-
Weight: 11.9 kg
Drilling Range
-
Drilling Diameter in Concrete (Hammer Drill Bits): 12 – 52 mm
-
Optimal Application Range in Concrete (Hammer Drill Bits): 30 – 50 mm
-
Drilling Diameter in Concrete (Breakthrough Drill Bits): 80 mm
-
Drilling Diameter in Concrete with Core Cutters: 50 – 150 mm
Total Vibration Values (Hammer Drilling in Concrete)
-
Vibration Emission Value (ah): 10.8 m/s²
-
Uncertainty (K): 1.5 m/s²
Total Vibration Values (Chiselling in Concrete)
-
Vibration Emission Value (ah): 10.6 m/s²
-
Uncertainty (K): 1.5 m/s²
Hammer Drilling in Concrete
-
Vibration Emission Value (ah): 10.8 m/s²
-
Uncertainty (K): 1.5 m/s²
Chiselling in Concrete
-
Vibration Emission Value (ah): 10.6 m/s²
-
Uncertainty (K): 1.5 m/s²
