Hisense 24,000 BTU Inverter Ducted Air Conditioner | Compact Low-Static System | R410A Refrigerant | HEAVY DC Series AUD-24UX

The Hisense AUD-24UX4 is a compact, high-performance inverter ducted air conditioner designed for both residential and commercial spaces up to 70 m². Offering powerful cooling and heating, low-noise operation, and flexible concealed installation, it delivers stable year-round climate control with energy efficiency and long-term reliability.

Key Product Highlights

1. 24,000 BTU (7.2 kW) Cooling / 8.5 kW Heating for medium-sized spaces
2. Low-static, slim-profile indoor unit (270 mm height) for limited ceiling spaces
3. Flexible rear or bottom air intake to suit various installation layouts
4. Inverter compressor technology for energy-efficient, precise climate control
5. Quiet operation with noise levels from just 37 dB(A)
6. Multiple comfort modes including Sleep, Smart, Super, and I-Feel
7. Wide temperature operating range from -15°C (cooling) to -10°C (heating)
8. Durable design with galvanized steel housing and leak-resistant drain tray
9. Built-in diagnostics and auto-restart for enhanced reliability
10. Wired controller included, with optional remote control available
11. 36-month warranty for long-term peace of mind

Technical Specifications

Performance

1. Cooling Capacity: 7.2 kW (24,565 BTU)
2. Heating Capacity: 8.5 kW (28,982 BTU)
3. Nominal Power Input: 2.24 kW
4. Coverage Area: Up to 70 m²
5. Airflow (m³/h): 800 / 950 / 1100
6. Noise Level (Indoor): 37 / 40 dB(A)
7. Inverter: Yes

Power Supply

1. Voltage: 220–240V
2. Frequency: 50 Hz
3. Phase: Single

Operating Temperature Ranges

1. Cooling: -15°C to +48°C
2. Heating: -10°C to +24°C

Refrigeration System

1. Refrigerant: R410A
2. Pipe Diameter: 9.52 mm (3/8") – Liquid / 15.87 mm (5/8") – Gas
3. Max Line Length: 30 m
4. Max Elevation Difference: 15 m

Dimensions & Weight

1. Indoor Unit (W × H × D): 900 × 270 × 720 mm
2. Outdoor Unit (W × H × D): 860 × 670 × 310 mm
3. Indoor Unit Weight: 32 kg
4. Outdoor Unit Weight: 51 kg

Design & Build

1. Series: HEAVY DC Inverter
2. Air Pressure Type: Low-static
3. Construction: Galvanized steel casing
4. Drain Tray: Polystyrene with condensate level controller

Controls & Features

1. Control Type: Wired controller (included)
2. Optional: Remote control
3. Modes: Timer, Sleep, Smart, Super, I-Feel
4. Safety: Auto-restart, diagnostics system
