Product Description

• RMS 400W
• USB/MP3/WMA
• Flashing Led Speakers
• Bluetooth
• Line In/USB/RCA/Karaoke Input/Guitar Input/Wired Party Chain




Sound Enhancement

Sound Mode

Balance, EQ Volume, Extra Bass, Jazz, Pop, Rock, Samba




Mechanical Features

Material Body

Wooden Box




Take Way

Hand Take




Sound Features

Sound Mode

Balance, EQ Volume, Extra Bass, Jazz, Pop, Rock, Samba




Drivers

L/R tweeter: Box type

Bass Port




L/R Tweeter Bar Freq Response

2KHz-20kHz




L/R Tweeter Speaker Unit Tweeter

2″ x 2




Woofer: Box type

Bass Port




Woofer: Box volume

24L x 2




Woofer: Bar Freq Response

50Hz-5kHz




Woofer: Speaker unit

6.5″ x 2




Terminals

Input

AC Outlet, Guitar Input (Pin Jack / φ6.35), Line In (Pin Jack / φ3.5), Mic Input (Pin Jack / φ6.35), USB Port for Service & Playback




Output

RCA for Party chain (Back), USB 0.5A x 2 (playback and charge)




Functions

Keys

Play/Pause, Power on/off, Volume +/-




Key

Tact Key




Decoder Function

AAC, Dolby Digital, Dolby Virtual Speaker, DTS Digital Surround, MP3 (Sampling Freq: 32kHZ to 48kHZ. Bit Rate: 32 to 320kbps), PCM (2ch), WMA (Sampling Freq: 32kHZ to 48kHZ. Bit Rate: 40 to 192kbps)




HDMI Function

4K Pass through (24p)




Bluetooth

A2DP / AVRCP, Bluetooth Codec: SBC, Bluetooth Function Version 4.2 / F-6699




Bluetooth Connectivity

6 Multi-Pairing




Party Chain

Wired Party Chain




Lighting Mode

Breath, Flashing, Racing




Smartphone app

APP. (Panasonic Music Streaming) iOS, NFC Control (Android)




Software Upgrade

SW upgrade from Main Board Socket, SW upgrade from USB Flash Drive




Eco

Auto Power Down (15 minutes to Standby when no source trigger)




Display

Display Method

Dimmer: Yes, LED




Amplifier

Amp Dimensions W x H x D

320 x 934 x 295 mm




Amp Type

2.0CH




Power Supply

Voltage

100-240AV




Frequency

50-60Hz




Power Consumption in Standby Condition Target

0.5W




Audio Accessories

O/I

Adding Special Language Default EN, Language Default EN




Warranty Card

Yes




Other Accessories

AC Adaptor, AC Cord, AC Plug Adaptor (PU / PX model)




POP

Yes




User Interface

Key

Tact Key




Radio Tuner

FM

FM (Stereo / Monaural)




FM Tuning Range (50kHz / 100kHZ)

87.5 – 108.0 MHz




Standard Spec

Tuner Area




Connectivity

Input

AC Outlet, Guitar Input (Pin Jack / φ6.35), Line In (Pin Jack / φ3.5), Mic Input (Pin Jack / φ6.35), USB Port for Service & Playback




Output

RCA for Party chain (Back), USB 0.5A x 2 (playback and charge)




Bluetooth

A2DP / AVRCP, Bluetooth Codec: SBC, Bluetooth Function Version 4.2 / F-6699




Features

Smartphone app

APP. (Panasonic Music Streaming) iOS, NFC Control (Android)
