Features:
- Slim design with planetary gears
- Reversible blade for particularly high economic efficiency
- Knob grip for comfortable and safe guidance
Technical Data
- Cutting capacity in steel (400 N/mm²), max.:2.8 mm
- No-load stroke rate:2,400 spm
- Material that can be processed
- Steel up to 400 N/mm² at 2.8 mm
- Smallest radius:38 mm
- Stroke rate under load:1,500 spm
- Weight:2.7 kg
- Tool dimensions (length):292 mm
- Tool dimensions (height):205 mm
- Cutting capacity in steel (600 N/mm²), max.:2.2 mm
- Cutting capacity in steel (800 N/mm²), max.:1.9 mm
- Cutting capacity in aluminium (200 N/mm²), max.:3.5 mm
Electric specifications
- Rated input power:500 W
- Power output:270 W
Total vibration values (Cutting sheet metal)
- Vibration emission value ah:16 m/s²
- Uncertainty K:1.5 m/s²
Noise/vibration information
- Sound pressure level:79 dB(A)
- Sound power level:90 dB(A)
- Uncertainty K:3 dB
Cutting sheet metal
- Vibration emission value ah:16 m/s²
- Uncertainty K:1.5 m/s²
