Feature
- Wall-mounted split type air-conditioner
- Heat & Cool
- Stylish flat panel
- Comfortable airflow
- Low noise level
- Auto-restart
- Filters to purify air
- Malaysian compressor
- Copper Condenser
- Compressor type: rotary
- Refrigerant type: R410
- Operating current: 2.6 amperes
- Color: White
Technical/Functional Specification
- Series: FCQF Series
- Indoor Model: No FCQF30ARV16
- Outdoor Model: No RGVF30ASV16
- Power supply: intake Outdoor unit
- Cooling Capacity: Rated Full/Half (min ~ max) kW 8.79
- Cooling Capacity: Rated Full/Half (min ~ max) Btu/h 29,992
- Power consumption (Cooling): Rated Full/Half (min~max) W 2,410
- Annual Power Consumption: kWh 1,866
- ISEER / ISEER Rank 3.65 / Non Inverter 2 Star
- Power Supply: V, Hz 1 , 230, 50
- Modes: Cool Mode, Fan Mode, Dry Mode
- Timer ON: Timer can be set from 1 hour to 12 hours
- OFF Timer can be set from 1 hour to 9 hours
- Auto Restart: Yes
Indoor Unit
- Front Panel Colour: White
- Indoor Dimensions: (H x W x D) 298 x 840 x 840
- Indoor Panel Dimensions: (H x W x D) 50 x 950 x 950
- Indoor Machine Weight: (Kg) 25
- Indoor Panel Weight: (Kg) 5.5
- Airflow rate: (H / HM / M / ML / L) m³/min (Cmm) 34.5 / 31 / 27.5 / 24 / 20
- Airflow rate: (H / HM / M / ML / L) f³/min (Cfm) 1,218 / 1,095 / 971 / 848 / 706
- Sound Levels: (H / MH / M / ML / L / SL) 45 / 41.5 / 38 / 35 / 32.5
Outdoor Unit
- Casing Colour: Ivory White
- Compressor Type: Rotary
- Refrigerant: R-32
- Motor Output: kW 1.6
- Dimensions: (HxWxD) mm 990 x 940 x 320
- Machine Weight: (Kg) 68
- ODU Sound Level: dB(A) 58
- Std. Interunit piping length: (m) 7.5
- Max. interunit piping length: (m) 20
- Max. installation level difference: (m) 10
- Piping Connection: (Gas/Liquid) mm (inch) ∅15.5/∅9.5 (5/8" ; 3/8")
- Operating Ambient: Temperature Range Cooling (Min ~ Max) °CDB 19° ~ 48°
