Basic Information
- Evvoli Name: EVDW-153HS
- Installation: Free Standing
- Color: Stainless Silver
- Capacity (place settings): 15
- Performance: A++
- Noise (dB(A)): 47
- Energy consumption per annum（kwh/annum): 270
- Energy consumption per cycle（kwh/cycle): 0.95
- Water consumption per annum(l/annum): 2800
- Water consumption per cycle(l/cycle): 10
Controls
- Type of control: Touch
- Control functions: Power, Program, delay+, delay-, Zone Wash, Child lock, Function, start/pause
- Delay time (hour): 1~24H
- Child Lock: Yes
Program Number 7
- Intensive or Heavy: Yes
- Normal: No
- ECO: Yes
- 90 Min: Yes
- Rapid: Yes
- Soak: Yes
- Glass: Yes
- Auto: Yes
Functions 3
- Power Wash\Strong Wash: Yes
- Extra Drying\Heated Dry: Yes
- Half load: No
- Dual Wash: Yes
Indicators
- Type of indicator: Screen
- Color of indicator: White
- Water sensor: Flowmeter
- Sensor Wash: Yes
- Antiflood device: Over-water level protection switch
Technical & Internal Specifications
- Voltage / V: 220-240V
- Frequency/Hz: 50
- Off mode(unit:W): 0.45
- Left on mode(unit:W): 0.49
- Rated power: 1760~2100W
- Inlet water pressure (Mpa): 0.04~1
- Power of heat element: 1800W
- Filter type Self-cleaning filter system
- Filter material: PP+30%T+AISI304
- Tub material: AISI430+AISI304
- Dispenser type: mini
- Water softener: Yes
- Removable top: Yes
- Drying system: Residual heating dry
- Type of inlet hose(standard,PEX,aqua-stop ): Standard
- Temperature of inlet hose: Cold water
- Power Cord Length: 1500mm
- Inlet hose length: 1500mm
- Outlet hose length (the all long): 1600mm
- Outlet hose length (Expose length outside the machine): 1400mm
Baskets
- Number Of Racks: 3
- Spray arms(Upper+Lower /Upper+Lower+top): Top+Upper+Lower
- Foldable bottom plate racks: Yes
- Top Basket(multi-function\one-piece): Yes
- Cup Shelf: 2
MECHANICAL KEY SPECIFICATION
- Product Dimension(w×d×h) mm: 598*600*845
- Package Dimension(w×d×h) mm: 645*645*890
- Unit net wight (kg): 45.5
- Unit gross wight (kg): 51
