Features:
- Smooth and flat finish enabled by consistent depth control mechanism and precisely machined flat aluminium base.
- Controlled planing due to compact design and optimised centre of gravity for steady planing
- Eliminates wood chip blockage via improved airflow design and providing flexibility to discard wood chips from either right or left side
Technical data
- Rated input power:700 W
- Planing width:82 mm
- Planing depth:0 mm
- Weight:2.7 kg
- Adjustable rebating depth:0 – 9 mm
- No-load speed:16,500 rpm
- Tool dimensions (width):160 mm
- Tool dimensions (length):262 mm
- Tool dimensions (height):174 mm
Noise/vibration information
- Sound pressure level:88 dB(A)
- Sound power level:99 dB(A)
- Uncertainty K:3 dB
Total vibration values
- Vibration emission value ah:2.8 m/s²
- Uncertainty K:1.5 m/s²
