Features:
- Precise results and little rework thanks to minimum discolouration and low levels of burr formation with “Expert for Steel” saw blades
- Integrated laser allows precise cutting guidance
- Up to 100% spark-free for a safe working environment
Technical Data
- Cutting capacity at rectangle 0º: 158 x 80 mm
- Cutting capacity at square 0º: 100 x 100 mm
- Cutting capacity at L-profile 0º: 110 x 110 mm
- Cutting capacity at rectangle 45º mitre: 85 x 85 mm
- Cutting capacity at square 45º mitre: 85 x 85 mm
- Cutting capacity at L-profile 45º mitre: 85 x 85 mm
- Depth x length x height: 327 x 517 x 383 cm
- No-load speed: 1,500 rpm
- Saw blade bore: 25.4 mm
Total vibration values (Cutting metal)
- Vibration emission value ah:3.5 m/s²
- Uncertainty K:1.5 m/s²
Noise/vibration information
- Sound pressure level:100 dB(A)
- Sound power level:113 dB(A)
- Uncertainty K:3 dB
