Features :
Fastest drilling rate in its class due to 1150 W motor and powerful hammer mechanism
SDS max comfort for easy and fast tool changes with one hand
Vibration Control (10 m/s² for drilling, 8 m/s² for chiselling) ensures convenient working, even in time-intensive applications
Technical data
Rated power input :1,150 W
Impact energy: 8,8 J
Impact rate at rated speed: 1500 – 3050 bpm
Rated speed :170 – 340 rpm
Weight: 6.8 kg
Length: 485 mm
Height: 260 mm
Bit holder: SDS-max
Drilling range
Drilling dia. concrete, hammer drill bits :12 – 40 mm
Opt. appl. range concrete, hammer drill bits :18 – 32 mm
Drilling dia. concrete, breakthrough drill bits :45 – 55 mm
Drilling diameter in concrete with core cutters :40 – 90 mm
Hammer drilling in concrete
Vibration emission value ah: 10.5 m/s²
Uncertainty K: 1.5 m/s²
Chiseling
Vibration emission value ah 7.5 m/s²
Uncertainty K 1.5 m/s²
Accessories
Auxiliary handle
Carrying case
Grease tube
Machine cloth
Voltage 240 V
